Why use CLDN18 antibodies for detecting CLDN18.2 in G/GEJ tumour samples?
CLDN18 antibodies can identify both CLDN18 isoforms— CLDN18.1 and CLDN18.2. But when evaluating G/GEJ tumour tissue, staining can be attributed to the presence of CLDN18.2 because2,3:
- CLDN18.1 is primarily expressed in adenocarcinoma lung tissue and its expression is undetectable in G/GEJ cancers3
- CLDN18.2 is normally present in gastric epithelium and is often retained in malignant gastric tissue3
Sample preparation and pre-analytics
Appropriate specimen handling and preparation are essential to ensure the accuracy of biomarker results.1
How to Prepare CLDN18.2 Samples for Testing
Takeshi Kuwata, MD, PhD
Sample preparation
Practices recommend daily tissue processor maintenance per the manufacturer recommendations, and rigorous quality maintenance of processor fluids, including formalin pH/purity and water contamination of alcohols.1
Cold ischemia time
Cold ischemia time should be limited to ≤60 minutes according to current recommendations.1
Fixation
Practices provide recommendations regarding dimensions and duration involved in sample fixation.1
Key dimensions1
Tissue should be completely submerged in fixative
Specimen thickness not to exceed 4-5 mm
Ensure a fixative volume to tissue mass ratio of no less than 4:1, with an optimal ratio of 10:1
Paraffin should be melted at <60°C
Specimen containing sufficient tumour tissue for analysis
Key durations1
As part of stabilization, tissue should be fixed in 10% neutral phosphate-buffered formalin (pH 7.0) for at least 6 hours and no longer than 24 to 36 hours
If the tissue has high fat content, fixation may require up to 48 hours
Suboptimal tissue fixation1
It is important to optimize pre-analytical variables to minimize staining artifacts, which can interfere with accurate scoring.
Cytoplasmic blushing due to suboptimal fixation, which can interfere with accurate membranous scoring.
Specimen preparation2
Routinely processed, FFPE tissues are suitable for use with IHC testing
Specimens that are FNA, cytology specimens or metastatic bone lesion do not qualify for CLDN18 staining
Tissue sections can be cut at approximately 4 µm (range: 3 µm-6 µm*)
Before staining, the cut slides should be dried completely either at room temperature (air dried) or by offline baking (baked in oven) at 60°C for 60 minutes*
*CLDN18-specific.
Storage conditions1
To ensure integrity of specimens, storage areas should be:
Dry
Pest-free
Room temperature (18°C to 25°C)
Testing
Options for evaluating CLDN18.2 IHC expression
A number of assays, antibodies, and platforms are available for the assessment of CLDN18.2 expression. Assays and antibodies include the VENTANA CLDN18 (43-14A) IVD Assay, the LSBio PathPlus™ CLDN18 Antibody, and the Abcam Recombinant Anti-Claudin 18 antibody (43-14A). Options for platforms include BenchMark ULTRA, Dako Autostainer, and Leica Bond.4
The list of antibodies/assays and platforms is not exhaustive, and the tests mentioned above are not currently FDA-approved companion diagnostics.
VENTANA CLDN18
(43-14A) IVD AssayLearn More
LSBio PathPlusTM
CLDN18 AntibodyLearn More
Abcam Recombinant Anti-Claudin 18 antibody (43-14A)Learn More
How to Test for CLDN18.2
Christoph Röcken, MD
Select appropriate controls
Appropriate controls are essential for the detection of CLDN18.2 in G/GEJ tumour samples. Here are some key points on their selection and use.2,5
Validation controls
Guidelines recommend that laboratories validate and/or verify IHC tests and should include positive, negative, and borderline tissue, reflecting the intended use of the assay.5
Tissue controls are commercially available through various providers.
Run controls
- It is recommended to use optimal run controls, including positives and negatives2
- Gastric intestinal metaplasia tissue is an example of an appropriate positive and negative control as it demonstrates2:
- Strong membranous staining in normal gastric epithelial cells
- Weak-to-moderate membranous staining of epithelial cells in areas of metaplasia
- Absence of CLDN18 staining in lamina propria, lymphocytes, smooth muscle, blood vessels, and peripheral nerve
- If the positive controls fail to demonstrate positive staining, results of the test specimen should be considered invalid2
- Known positive tissue controls should be utilized only for monitoring performance of reagents and instruments, not as an aid in determining specific diagnosis of test samples2
Platforms and antibody performance characteristics
In a study assessing the reproducibility and comparability of three CLDN18 antibodies and IHC staining platforms across a cohort of 27 global laboratories4,†,‡:
- Analytical performance (accuracy, sensitivity, and specificity) of the VENTANA CLDN18 (43-14A) IVD Assay was >95% and reproducible across the 27 laboratories vs consensus reference results4
- Analytical performance was equivalent to the VENTANA (43-14A) IVD Assay for the LSBio antibody when stained on the Dako or Leica platform4
- Staining was reproducible for the LSBio antibody4
† Antibodies in the study comprised of the VENTANA CLDN18 (43-14A) IVD Assay from Roche Tissue Diagnostics, the PathPlus™ CLDN18 Antibody from LSBio, and the Claudin-18 Antibody from Novus Biologicals. Platforms comprised of BenchMark ULTRA, Dako Autostainer, and Leica Bond.4
‡ Consensus reference scores from all antibodies for each sample were determined by central pathology review. CLDN18.2 positivity was defined with a threshold of ≥75% of tumour cells expressing membranous CLDN18 with moderate-to-strong (≥2+) staining intensity. Accordingly, participating pathologists were required to submit a binary positive/negative call as well as an estimation of the percent of cells stained. Laboratory-submitted IHC scores were compared to the reference consensus score and considered discordant if the positive/negative binary result differed. Statistical analysis was performed for comparison, and an acceptance criteria of 85% (≥0.85) was applied.4
CLDN, claudin; CLDN18.1, claudin 18 isoform 1; CLDN18.2, claudin 18 isoform 2; FDA, US Food and Drug Administration; FFPE, formalin-fixed, paraffin-embedded; FNA, fine-needle aspirate; G/GEJ, gastric/gastroesophageal junction; IHC, immunohistochemistry; IVD, in vitro diagnostic.
References: 1. Compton CC, Robb JA, Anderson MW, et al. Preanalytics and precision pathology: pathology practices to ensure molecular integrity of cancer patient biospecimens for precision medicine. Arch Pathol Lab Med. 2019;143(11):1346-63. 2. Ventana CLDN18 (43-14A) assay [package insert]. Mannheim, Germany: Roche Diagnostics GmbH. 3. Sahin U, Koslowski M, Dhaene K, et al. Claudin-18 splice variant 2 is a pan-cancer target suitable for therapeutic antibody development. Clin Cancer Res. 2008;14(23):7624-34. 4. Jasani B, Schildhaus HU, Taniere P, et al. Global ring study determining reproducibility and comparability of CLDN18 testing assays in gastric cancer. Poster presented at: ESMO Targeted Anticancer Therapies Congress; March 6-8, 2023; Paris, France. 5. College of American Pathologists. IHC assays—New evidence-based guideline for analytic validation (04-01-2004). https://documents.cap.org/documents/ihc-validation-webinar-handout.pdf. Accessed 03-30-2023. 6. ESMO Gastric Cancer Living Guidelines (07-2023). https://www.esmo.org/living-guidelines/esmo-gastric-cancer-living-guideline/diagnosis-pathology-and-molecular-biology/article/diagnosis-pathology-and-molecular-biology. Accessed 09-07-2023. 7. Piening B, Bapat B, Weerasinghe RK, et al. Improved outcomes from reflex comprehensive genomic profiling-guided precision therapeutic selection across a major US healthcare system [Abstract 6622]. J Clin Oncol. 2023;41 (Suppl 16).
